18 MM 4 Step (Half Rotary)

Name: 18 MM 4 Step (Half Rotary)
Brand: SOLITRACK ENGINEERS
Price: 8 INR
Availability: InStock

Price 8 INR/ Number

Get a Price/Quote

18 MM 4 Step (Half Rotary) Specification

Circuit Type
SPST

Automation Grade
Manual

Protection Level
IP40

Number of Module
Single

Temperature Range
-20C to +55C

Max. Current
1A

Mechanical Life
>10,000 operations

Finish Type
Matte

Rated Voltage
220 Volt (V)

Response Time
Instantaneous

Product Type
18 Mm Rotary Switch For Fan

Material
Nylon

Insulation Resistance
>100 M at 500V DC

Contact Resistance
<30 m at 2-4V DC

Max. Voltage
250V AC

Operating Temperature
-20C to +55C

Stoke
4 Steps

Size
18mm

Color
Orange

Weight
Approx. 12g

Mounting Type
Panel Mount

Current Rating
1A

No Of Poles
1 Pole

Humidity
Up to 85% RH

Terminal Type
Solder Lug

Flammability Rating
UL94V-0

Switch Travel
2.5 mm per step

Rotation Angle per Step
90

Brand Compatibility
Universal

Dielectric Strength
1500V AC for 1 min

Contact Material
Silver Alloy

RoHS Compliance
Yes

Torque Requirement
0.2 Nm Max

18 MM 4 Step (Half Rotary) About

The 18 MM 4 Step (Half Rotary) switch is recognized for favorable reviews thanks to its exceptional performance and uncompromising quality. Featuring the latest design updates, it boasts a grandiose profile with a vibrant orange nylon body and durable silver alloy contacts. Compatible with universal brands, this prime switch comes with solder lug terminals and a reliable SPST circuit. Enhanced by a UL94V-0 flammability rating, reduced contact resistance, and robust mechanical life exceeding 10,000 operations, it is RoHS compliant, assuring safety and longevity in multiple panel-mounted applications across India.

Prominent Uses and Applications of 18 MM 4 Step (Half Rotary)

The 18 MM 4 Step (Half Rotary) is a prime solution for panel meters, control instrument panels, and industrial automation systems. Used as a selector switch, it ensures accurate and reliable process control. Its grandiose design suits usage in electrical panels and machinery where precise multi-step switching is required. This exceptional component stands out in sites of application like factories, testing laboratories, and technology workstations, guaranteeing optimized and effortless operation in demanding environments.

Flexible Supply, Swift Delivery, and Secure Transactions

With consistent supply ability, the 18 MM 4 Step (Half Rotary) can be dispatched following proposal amount confirmation. Payment terms are accommodating, supporting a smooth exchange and speedy processing. Clients can anticipate prompt arrival, with delivery timeframes tailored according to order size and urgency. Each unit is meticulously packed and shipped across India, assuring reliable delivery and satisfaction from manufacturer or supplier to end user, whether for single or bulk requirements.

FAQ's of 18 MM 4 Step (Half Rotary):

Q: How do I install the 18 MM 4 Step (Half Rotary) switch?

A: The installation process is straightforward: mount the switch onto your panel using the provided panel mount option, then use solder lugs for secure terminal connections according to standard wiring procedures.

Q: What are the main benefits of using this rotary switch in my equipment?

A: This switch offers reduced contact resistance, high dielectric strength, favorable user reviews, and a robust mechanical life of over 10,000 operations, ensuring reliable performance and safety in demanding environments.

Q: Where can I use the 18 MM 4 Step (Half Rotary) switch?

A: It is ideal for use in industrial control panels, laboratory instruments, and automation systems, thanks to its universal brand compatibility and exceptional durability.

Q: When is the typical delivery time for orders?

A: After confirmation of the proposal amount and payment terms, delivery is prompt, with arrival times adjusted based on the size of your order and logistical requirements.

Q: What makes the contact material and protection level of this switch unique?

A: The switch features silver alloy contacts for optimal conductivity and an IP40 protection level, ensuring safe and reliable operation in various indoor environments.

Q: How does RoHS compliance and flammability rating benefit users?

A: RoHS compliance ensures environmentally friendly usage, while the UL94V-0 flammability rating provides excellent fire resistance, enhancing overall safety for all applications.
